Specifications:
- Inputs: 16 opto-isolated inputs (groups of two)
Isolation: up to 1000Vrms
Voltage range, OFF: < ±1V
Voltage range, ON: > ±10V
Current limit resistor: 10 kOhm, 0.25W
Input delay, OFF to ON: < 25µs
Input delay, ON to OFF: < 100µs
Interrupts: IRQ 5,9,10,11,15 selectable on channel 0
Connector: 26-pin ribbon cable connector
- Outputs: 48 digital o.c. (output pull-up) outputs
(one common GND, 4 groups of 12)
Voltage, load: 50V DC
Max current load (NPN): 400mA / BYTE
Max current load (PNP): 100mA / Channel
Saturation: Max 1.6V
Connector: 4x16-pin ribbon cable connector
- Physical/Environment:
Dimensions: 96x90mm
Temperature range, operating: -20°C to +70°C
Temperature range, storage: -40°C to +85°C
Humidity: 0 to 90% RH, non-condensing
|
