Specifications:
- Analogue voltage inputs
Number of channels: 16 (single ended)
Resolution: 12 bits
Conversion time: 22 µs typical
Voltage ranges: 0-1V, 0-2.5V, 0-5V, and 0-10V (software selectable)
- Analogue current inputs (PV-2019 only)
Number of channels: 8 (single ended)
Resolution: 12 bits
Conversion time: 22 µs typical
Current ranges: 0-20mA
- Analogue outputs (PV-2019 only)
Number of channels: 2
Resolution: 12 bits
Output speed: 25 µs
Ranges: 0-10V, 0-20mA, and 4-20mA (software selectable)
- Digital inputs
Number of channels: 8
Logic "1" Uin: > ±10V
Logic "0" Uin: < ±1V
Isolation voltage: 1000V rms
- Digital outputs
Number of channels: 8 (open collector)
Max output current: 10mA per channel
Isolation voltage: 1000V rms
- Counters
Number of channels: 2
Counting range: 32 bits (0 - 4294967295)
Logic "1" Uin: > ±10V
Logic "0" Uin: < ±1V
Isolation voltage: 1000V rms
- Power consumption
5V current 260-630 mA (depending on output usage)
- Environmental
Operating temperature: -20°C to +70°C
|
